2 Inch Blue Color High Efficiency 600 Ton Pressure Force Manual Hose Crimping Machine No Power Needed From 6-51mm Crimping Range And 10 Interchangeable Dies For Hydraulic Applications

2 Inch Blue Color High Efficiency 600 Ton Pressure Force Manual Hose Crimping Machine No Power Needed From 6-51mm Crimping Range And 10 Interchangeable Dies For Hydraulic Applications

Nom De Marque:	FY
Numéro De Modèle:	FY-51CSD
Nombre De Pièces:	1 ensemble
Prix:	USD$ 1300
Conditions De Paiement:	LC, D/A, D/P, T/T, MoneyGram, Western Union
Capacité à Fournir:	300 ensembles par mois

Informations détaillées

Description du produit

Informations détaillées

Lieu d'origine:

Shanghai, Chine

Certification:

Documents:

Poids:

200 kg

Condition:

Nouveau

Dimension (l*l*h):

550*670*555MM

Garantie:

Service après-vente assuré:

Support technique vidéo, support en ligne

Puissance (w):

Tension:

0V/sans=manuel

Force de sertissage:

600T=0,6MT

Couleur:

Bleu ou comme demande personnalisée

Plage de sertissage:

1/4"à2'',1/4''-2'',6-51mm

Nom du produit:

Machine à sertir manuelle de tuyau de force de pression de 600 tonnes de rendement élevé de couleur

Application:

Tuyau à sertir/sertissage de tuyau

Dies gratuits:

10 ensembles

Pression nominale:

70 MPA=700 bars

Mots-clés:

machine de rabattement manuelle, machine de rabattement de tuyau hydraulique

Détails d'emballage:

Exporter la boîte en bois standard

Capacité d'approvisionnement:

300 ensembles par mois

Mettre en évidence:

2 inch manual hose crimping machine

600 ton pressure force crimper

interchangeable dies hose crimping tool

Description du produit

2 Inch Blue Color High Efficiency 600 Ton Pressure Force Manual Hose Crimping Machine No Power Needed From 6-51mm Crimping Range And 10 Interchangeable Dies For Hydraulic Applications

2-Inch Blue Color High-Efficiency Manual Hose Crimping Machine: Power Without Electricity

Overview

Introducing our 2-Inch Blue Color High-Efficiency Manual Hose Crimping Machine, a robust and reliable solution designed for hydraulic applications where power access is limited or portability is paramount. This machine delivers an impressive 600 Ton pressure force without requiring any external power source, making it an ideal choice for on-site repairs, mobile service units, and workshops in the USA, Europe, and Southeast Asia. Its vibrant blue finish signifies its durable construction and readiness for demanding tasks in hydraulic/car repair shops, and the oil and hose service industries.

Key Features and Characteristics

This manual hose crimping machine is engineered for efficiency and versatility, providing professional-grade crimps for a wide range of hydraulic hoses. It comes equipped with 10 interchangeable dies, covering a crimping range from 6mm to 51mm (up to 2 inches).

•Exceptional Crimping Force: With a powerful 600 Ton (6000 KN) pressure force, this machine ensures consistent, secure, and leak-proof crimps for high-pressure hydraulic hoses and fittings. This capability is crucial for maintaining the integrity and safety of hydraulic systems.

•No Power Required: Operating entirely manually, this crimper is independent of electrical power, offering unparalleled flexibility for field service, remote locations, or emergency repairs. This feature significantly reduces operational costs and expands its utility.

•Wide Crimping Range: The machine handles hose sizes from 6mm to 51mm (up to 2 inches), accommodating a broad spectrum of hydraulic hose types commonly found in automotive, industrial, and agricultural machinery.

•10 Interchangeable Dies: A comprehensive set of 10 dies is included, allowing for quick and easy changeovers between different hose diameters and fitting types. This enhances efficiency and reduces downtime during varied crimping tasks.

•High Efficiency and Durability: Constructed from high-quality materials, this machine is built for longevity and consistent performance. Its design prioritizes high efficiency, enabling rapid and accurate crimps with minimal effort.

•Compact and Portable Design: While delivering substantial power, the machine maintains a manageable size and weight (approx. 200kg), making it relatively easy to transport and set up in various working environments.

Advantages for Your Business

Investing in this 2-Inch Manual Hose Crimping Machine offers significant benefits for businesses in the USA, Europe, and Southeast Asia:

•Operational Independence: The absence of power requirements provides complete freedom to perform crimping operations anywhere, anytime, without relying on generators or electrical outlets. This is a major advantage for mobile service providers.

•Cost-Effective Solution: Reduce electricity bills and maintenance costs associated with powered machines. The manual operation also means fewer complex components, leading to lower repair expenses.

•Versatility Across Applications: Ideal for a diverse clientele, including heavy equipment operators, agricultural businesses, marine services, and general industrial maintenance, allowing your business to cater to a broader market.

•Reliable Performance: Achieve factory-quality hose assemblies that meet industry standards, enhancing the safety and operational lifespan of hydraulic systems for your customers.

•Market Competitiveness: Offer rapid, on-site hose repair services that minimize client downtime, giving your business a competitive edge in fast-paced markets.

Technical Specifications

Model	FY-51CSD Manual Crimper
Crimping Range	6-51mm (1/4"-2" inner diameter)
Crimping Force	600 Tons
Maximum Open Diameter	114mm
Die Sets	10 sets
System Pressure	70 MPa
Accuracy	0.01mm
Work Efficiency	10 pieces/hour
Dimensions	550mm * 670mm * 555mm
Weight	200kg

Additional Features

Small size and light weight for easy transportation
World-famous hydraulic pump system
High accuracy and precision crimping
High efficiency with Finn Power Dial control
Stable performance even after years of service

Machine Features

Crimping Dial

High accuracy and stability with long service life

Compact Design

FY-51CSD weighs only 200kg with compact dimensions for easy transportation to any location

Quick Die Sets Installation

FY-51CSD enables rapid die set changes and installation to save time and improve productivity

Customization Options

Different machine colors or company LOGO can be customized according to customer requirements

Application Fields

The portable FY-51CSD crimping machine offers flexible hose crimping capabilities for on-site applications without power supplies. With different die sets, it can perform various tasks including hydraulic hose assembly up to 2 inches, connecting steel tubes, pressing wires and cables, and more.

Frequently Asked Questions

What maximum hose size can this machine crimp?

The machine crimps hoses up to 2 inches (51mm) in diameter.

Is electricity required to operate the crimper?

No—this is a manual crimping machine designed to work without electrical power.

How many dies are supplied and can I get additional dies?

Ten interchangeable dies are included. Additional dies are available to match specific fittings or non-standard hose sizes—contact the supplier for options.

Is this machine suitable for high-pressure hydraulic hoses?

Yes. With a 600T crimping force, it is designed to produce secure crimps for high-pressure hydraulic hose assemblies when used with correct dies and fittings.

What maintenance is required?

Routine checks include lubricating moving parts, inspecting dies for wear, and tightening fasteners. The manual design simplifies maintenance compared to electric systems.
